Three roll rubber calender machine/rubber calender mill
Application:
Rubberizing and fractioning of textile material ,rubberizing of
wirecord fabric, sheet, and counter plate(embossed) of rubber
material, separation of fabric and film, as well as joint of
multi-layer laminate film.
General design:
It mainly contains roller, rack , backplane, adjustment, device ,
transmission system, roller temperature control device, security
device ,lubricating device,etc.
Features :
1.The roller is made of chilled cast iron alloys, whose work
surface has high hardness , wear-resistent and durable life. Steam
, cooling water, and heat-conducting oil can pass into the rollers
cavity, so that the working temperature can be adjusted in order to
meet the technical requirements.
2.Roll spacing can be adjusted both by manual or electric mode .
3.Roller bearings lubricating can adopt drier oil or dilute oil.
| Type |
Roll
Diameter mm | Roll working length
mm |
Speed Ratio of rolls |
Middle-roll linear speed
m/min |
Adjusting nip range
mm |
Min.calendering product thickness
mm |
Calendering product width
mm |
Motor power kw |
Overall size mm |
Weight ton |
| XY-3R230X630 | 230 | 630 | 1:1:1
1:1.2:1 | 0.8-8 | 0-7 | 0.2 | 500 | 7.5 | 3168x890x1830 | 3 |
| XY-3R252X720 | 252 | 720 | 1:1:1 | 2-15.9 | 0-10 | 0.2 | 550 | 22 | 3950x1720x1210 | 5.5 |
| XY-3R360X1120 | 360 | 1120 | 1:1:1
0.733:1:1
0.733:1:0.733 | 3-20 | 0-10 | 0.2 | 920 | 45 | 6500x1500x2440 | 14 |
| XY-3R400X1200 | 400 | 1200 | 1:1:1
1:1.383:1.383
1:1.383:1 | 3-26.39 | 0-10 | 0.2 | 1200 | 55 | 6300X1500X2440 | 18 |
| XY-3R450X1400 | 450 | 1400 | 1:1:1
1:1.5:1 | 2.62-26.2 | 0-10 | 0.2 | 1250 | 75 | 7320X2200X2900 | 21 |
| XY-3R610X1730 | 610 | 1730 | 1:1:1
1:1.4:1 | 5.4-54 | 0-20 | 0.15 | 1500 | 160 | 7010X3950X3730 | 42 |
| XY-3R710X1800 | 710 | 1800 | 0.5-1 | 4-40 | 0-30 | 0.2 | 1600 | 90X2
110X1 | 9950X3050X4540 | 90 |
| XY-3R710X2130 | 710 | 2130 | 1:1:1 | 8-50 | 0-20 | 0.15 | 1900 | 185 | 7650X4560X4080 | 67 |
| XY-3R800X2500 | 800 | 2500 | 0.5-1 | 3-30 | 0-30 | 0.2 | 2200 | 132X3 | 11400X3200X5050 | 110 |
| XY-3R860X2500 | 860 | 2500 | 0.5-1 | 4-40 | 0-30 | 0.5 | 2200 | 132X3 | 12000X3200X5100 | 130 |
