5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509

    Buy cheap 5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509 from wholesalers

    Buy cheap 5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509 from wholesalers
    • Buy cheap 5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509 from wholesalers

    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509

    Ask Lasest Price
    Brand Name : huicai
    Price : $16,000.00/sets >=1 sets
    • Product Details
    • Company Profile

    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509

    Product Overview

    XQL-80/120/125


    Rubber Cutter

    The machine is High-yield steel wire tire crusher, Break the steel tire block (50x50) into 16 mesh to 40 mesh rubber powder.
    FEATURES AT A GLANCE
    Manufactured by special process
    Ordinary rail and alloy rail for customers to choose
    All hard tooth surface gear reducer of 35CMo material is used to reduce speed
    Low noise and large transmission power
    Wear and impact resistance
    Using hardened gear for rotation to improve the service life of the whole machine
    Using foreign technology welding steel base, no deformation, no fracture, avoid misoperation loss
    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509
    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509
    Right elevation
    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509
    Left elevation
    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509
    Front elevation
    PRODUCT SPECIFICATIONS
    Model
    XQL-80
    XQL-120
    XQL-125
    width of knife
    660mm
    760mm
    760mm
    knife stroke
    680mm
    680mm
    680mm
    cylinder toal pressuer
    80KN
    120KN
    125KN
    stroke time
    14-16S
    13-16S
    13-16S
    motor power
    5.5KW
    11KW
    14KW
    (l*w*h)cverall size
    2122*1440*2509MM
    1950*1400*2338
    2300*1500*2530
    Gross Wieght
    1600KG
    2000KG
    2600KG
    Successful Project
    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509

    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509

    5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509

    Quality 5.5 kW Rubber Cutter for Heavy Duty Applications 2122*1440*2509 for sale
