    ISO9001 Certified Rubber Machinery Customizable Rubber Injection Molding Machine

    Ask Lasest Price
    Brand Name : Huicai
    Supply Ability : 120 Set/Sets per Month
    Price : $2,000.00 - $8,000.00/sets
    • Product Details
    • Company Profile

    ISO9001 Certified Rubber Machinery Customizable Rubber Injection Molding Machine

    Technical Parameter:


    Parameters

    Model

    XZB-630

    XZB-1000B

    XZB-1000A

    XZB-1600

    XZB-2000

    XZB-3500

    Mold-locking force(KN)

    630

    1000

    1000

    1600

    2000

    3500

    Injection pressure(MPa)

    90

    100

    110

    110

    100

    115

    Material tank size(mm)

    Φ70*250

    Φ80*220

    Φ80*255

    Φ80*255

    Φ90*300

    Φ110*385

    Block stroke(mm)

    300

    300

    300

    300

    300

    350

    Inject and press stroke(mm)

    360

    350

    380

    380

    450

    585

    Thermo-plate size(mm)

    440*480

    440*480

    520*540

    520*540

    550*600

    680*750

    Max. distance of thermo-plate(mm)

    300~400

    270~400

    190~400

    200~480

    180~480

    350~600

    Motor power(KW)

    4

    4+2.2

    4+2.2

    4+2.2

    5.5+3

    7.5+5.5



    1,Injecting rubber after the mould being blocked, high molding pressure in inner cavity of the mould, high density construction of products, priced size with less scurf.


    2,High speed open/close molds, high production efficiency, low blocking speed, protect mold.


    3,Automatic in/out mold and ejector device, low labor strength.
